直流变频落地扇及空清机马达解决方案

直流变频落地扇及
空清机马达解决方案

Solution of DC Frequency Converter Floor Fan and Air Cleaner Motor

环保

ENVIRONMENTAL PROTECTION

节能

energy conservation ENERGY CONSERVATION

舒适

Comfortable

落地扇及空清机马达

Floor fan and air cleaner motor

方案规格

  • 输入电压:DC24V
  • 电机功率:20W/30W
  • 保护机制:过压/过流/堵转/自订
  • 速度控制:开环/闭环/自订
  • 控制讯号:PWM/DCV/自订
  • 输出讯号:FG/自订

3大特征

THREE CHARACCTERISTICS

DC Frequency Converter Floor Fan and Air Cleaner Motor

PCB面积减少50%

PCB AREA REDUCED BY 50%

三相弦波驱动技术

THREE-PHASE CHORD
WAVE DRIVE TECHNOLOGY

产品特征

PRODUCT CHARACCTERISTICS

零件减少30%

PARTS REDUCED BV 30%

主要器件

XINDAMAO MAIN COMPONENTS

DC Frequency Converter Floor Fan and Air Cleaner Motor

采用三相弦波驱动技术,可有效降低运转时的振动及噪音,
并结合电力电子技术对马达电机进行变频控制,达到较为卓越的效能,进而提高环 保节能及舒适的生活质量.

XN3711
-马达驱动芯片

XDD4903
-PNMOS管

XN178
-贴片式霍尔感测器

REALITY

ENVIRONMENTAL

环保节能舒适

Xinergy Microelectronic Ltd is located in the National Torch High- Tech Park in Xiamen. It is a professional design enterprise engaged in simulation, digital simulation and motor drive control integrated circuits.

三相弦波驱动技术

可有效降低运转时的振动及噪音,并结合电力电子技术对
马达电机进行变频控制,达到较为卓越的效能,进而提高环保节能及舒适的生活质量。
